MODULAR PARTS WASHER
JCC-MODULE
The JCC-Module is a compact, yet powerful, modular parts washer for industrial applications. It is designed for precision cleaning, drying, and chip and oil removal. Engineered for easy integration into production lines or transfer machines, this modular system delivers consistent results—ensuring optimal part quality, longer equipment life, and efficient cycle times.
Despite its incredibly compact width of only 600mm, the JCC-Module easily tackles chips from tapped and blind holes with its Swing-Arm Targeted Cleaning feature.
The high-flow, multi-nozzle system quickly washes away chips and oil from the workpiece exterior. Eliminating the need for manual chip removal and inspection for lower production costs and streamlined operations.
The secret to high-speed, high-precision cleaning: Swing-Arm Targeted Cleaning（PAT.）
The Swing-Arm Targeted Cleaning system synchronizes the workpiece’s rotation axis with the nozzle’s three servo axes (moving up/down and left/right). This continuously targets holes while spraying, ensuring thorough chip removal from tapped and blind holes with pinpoint accuracy.
Additionally, with multi-axis high-speed positioning and high-volume spraying from multiple nozzles, you get rapid, full-surface cleaning of the entire workpiece, boosting efficiency without sacrificing precision. The JCC Module is engineered for high-performance cleaning and degreasing of metal components. In particular, it's a top choice for manufacturers in the automotive, aerospace, and fluid power industries seeking space-saving solutions without compromising performance.
Designed for easy implementation and every day use.
The JCC-Module is all about convenience. At just 600mm wide, its compact design fits seamlessly into even tight factory spaces—no need for major layout changes.
Need more functionality down the line? No problem. You can add necessary features and processes later, integrating them smoothly into existing production lines.
Seamless automation and labor savings.
JCC-Module: Recipient of the Good Design Award
The JCC-Module proudly earned the 2021 Good Design Award, recognized for its ergonomic, modular design. Focusing on user-friendliness and ensuring effortless operation, whether using a single unit or integrating multiple units in a lineup.
Key Features of the JCC-Module Parts Washer
- Compact & Modular: Easy to adapt and integrate into any factory setup.
- Ergonomic Design: Optimized height enhances comfort and usability, allowing for intuitive workflow handling, smooth operation, and effortless maintenance.
- Functional Color Coding: Thoughtful color division enhances usability, so key components are easy to distinguish at a glance.
| Product Name | JCC-Module: Modular Washer |
| Applications |
・Removal of cutting chips stuck in tapped holes and blind holes ・Removal of chips and oil adhering to the entire surface of the workpiece, degreasing Application examples: parts for EV/HV vehicles, transmission gears, shafts, car air conditioning units, etc. |
| Washing Specifications | 1.0MPa×100L/min or 7.0MPa×15L/min |
| Controller | CNC |
| Positioning | Oscillation (Servo) + Up/Down (Servo) |
| Machine Dimensions | W 600mm × D 3,000mm × H 1,850mm |
| Applicable workpiece size |
W 250mm × D 100mm × H 450mm *Workpiece size is indicative; larger workpieces may also be accommodated. Additionally, larger workpieces can be cleaned with the JCC-MULTI as well. |
| Machine Weight | 1,600kg |
